Product Introduction
This equipment is a 16-inch industrial-grade 90° fixed-angle single-head cutting saw, featuring a heavy-duty structure and a stable right-angle cutting system, specifically designed for high-precision batch cutting of aluminum alloy doors and windows, curtain walls, and industrial aluminum profiles.
Key Technical Features
Industrial-Grade 90° Fixed Angle Structure System: Utilizing a high-rigidity body and a fixed angle locking design, the cutting structure remains stable during long-term operation.
16-inch Industrial Saw Blade Cutting System: Equipped with a 400mm industrial-grade saw blade, improving cutting range and material adaptability, meeting the processing needs of various aluminum profile specifications, and reducing equipment change frequency.
Stable Clamping and Anti-Offset System: Employing a pneumatic clamping structure, it firmly secures materials during cutting, reducing vibration and offset, and improving cutting stability and processing safety.
Industrial-Grade Power Drive System: Featuring a high-torque industrial motor, it supports long-term continuous operation, suitable for high-intensity batch production environments, ensuring equipment operational stability.
Industrial Safety Protection System: Equipped with a fully enclosed protective structure and emergency stop device, complying with international industrial safety standards, improving operational safety and on-site compliance.
Technical Specifications
|
Item |
Specification |
|
Saw Blade Size |
400 mm (16 inch), 120T Carbide Blade |
|
Cutting Angle |
90° Fixed |
|
Cutting Accuracy |
±0.1 mm (Structural Positioning Standard) |
|
Motor Power |
2.2 kW (Optional 3.0 kW) |
|
Spindle Speed |
2840 / 3200 rpm |
|
Max Cutting Capacity |
120 mm × 200 mm (W × H) |
|
Working Air Pressure |
0.5 – 0.8 MPa |
|
Air Consumption |
60 L/min |
|
Voltage |
380V / 50Hz / 3 Phase (Custom 220V / 440V, 60Hz available) |
|
Feeding Mode |
Semi-automatic Pneumatic Feed System |
|
Machine Weight |
Approx. 450 kg |
|
Machine Dimension |
850 × 850 × 1350 mm |
Application Scenarios
Aluminum Alloy Door and Window Manufacturing Industry: Suitable for batch cutting and processing of door and window profiles, improving standardized production capabilities and product consistency.
Curtain Wall Engineering and Building Structure Processing: Suitable for cutting aluminum profiles for large-scale projects, improving the stability of structural component processing and project delivery efficiency.
Industrial Aluminum Profile Processing Enterprises: Suitable for batch processing of industrial profiles and structural components, improving production efficiency and processing stability.
Export-Oriented Processing and Trading Enterprises: Suitable for OEM and wholesale distribution systems, improving the standardized output capability of equipment.
Quality Control and Delivery Standards
Standardized Production System Control
All equipment is manufactured based on unified industrial standards, ensuring product performance consistency and reproducibility.
Pre-shipment Real Cutting Tests
Each piece of equipment undergoes actual material cutting tests to ensure that angle accuracy and operational stability meet factory standards.
Long-Term Operational Stability Verification
Continuous operation tests verify the stability and durability of the equipment in a batch production environment.
After-Sales Support
Remote Technical Support System
Provides video and online guidance services to assist customers in installation and commissioning.
Standard Warranty Service 12-18 Months Core components come with a standard warranty, ensuring long-term stable equipment operation.
Long-Term Spare Parts Supply System Standardized supply of key components ensures long-term equipment maintenance and production continuity.
Global Export Documentation Support Provides CO, Form E, and other customs clearance documents to help clients reduce import process risks.
Company Strengths
Extensive Industry Experience
Kanghong Building Materials Technology Co., Ltd. specializes in R&D, manufacturing, and sales of aluminum door, window, and curtain wall equipment. With years of industry focus, the company has built mature production experience and technical know-how.
Strong R&D Capability
Supported by a professional R&D team, the company continuously develops and integrates advanced technologies to improve machining accuracy, production efficiency, and machine stability.
Modern Manufacturing System
Equipped with advanced production facilities and CIMS management systems, we integrate design, manufacturing, and quality control to ensure consistent product quality and efficient delivery.
Strict Quality Control
A full-process quality inspection system is implemented from raw materials to final shipment, ensuring stable performance and reliable machine operation.
Customized Solutions
We provide tailored equipment and production line solutions based on customer profiles, production capacity, and process requirements.
Professional Technical Support
We offer layout design, installation guidance, operator training, and after-sales support, with a 12-month warranty (excluding wear parts) to ensure smooth production startup.
Global Market Experience
With stable quality and professional service, our equipment is exported worldwide and trusted by distributors, manufacturers, and engineering contractors.
FAQ
Q: Is this 16-inch single-head saw suitable for mass production?
A: Suitable for medium-to-high-intensity mass production scenarios. The equipment features a stable feeding and fixed 90° cutting structure, supporting long-term continuous operation and meeting the daily batch cutting needs of door and window factories and aluminum profile processing plants.
Q: What is the biggest advantage of a single-head saw compared to a double-head saw?
A: Single-head saws offer greater flexibility and cost advantages. They can handle various lengths and non-standard profiles, have lower equipment investment costs, and are more suitable for multi-specification orders and small to medium-sized processing plants.
Q: Is the cutting accuracy of the equipment stable? Will there be deviations after long-term use?
A: The equipment adopts a high-rigidity structure and a fixed angle design, maintaining stable cutting accuracy during long-term operation and effectively reducing the risk of angle deviation, making it suitable for continuous production environments.
Q: Is the operation complex? Is a skilled technician required?
A: The operating procedure is standardized. General workers can operate it independently after simple training, without requiring high-level technical experience, effectively reducing the company's reliance on skilled workers.
Q: What materials can the equipment cut?
A: Mainly used for aluminum alloy door and window profiles, curtain wall profiles, and industrial aluminum profiles. It can also be applied to some lightweight non-ferrous metal materials, depending on customer processing requirements.
Q: Does it support different national voltage standards?
A: Custom voltages are supported, including 380V / 220V / 440V / 50Hz / 60Hz, etc., adaptable to different power standards in the Middle East, Europe, America, and South America.
Q: What is the typical delivery time?
A: Standard models typically have a delivery time of 10–15 days; for OEM customization or bulk orders, the delivery time is generally around 25–35 days.
Q: Is the equipment tested before leaving the factory?
A: Each piece of equipment undergoes actual cutting tests and continuous operation tests before leaving the factory to ensure it meets industrial standards. Test videos or quality inspection reports are provided.
Q: What kind of after-sales support is provided if the equipment malfunctions?
A: Remote video technical support is available, with rapid response via WhatsApp or email; core components are covered by warranty, and global spare parts shipping is supported.
Q: Does it support OEM/ODM customization? Is it suitable for distribution?
A: OEM/ODM customization is supported, including body color, logo, nameplate, and voltage standard, making it suitable for overseas distributors and brand agents for local market promotion.
