Product Introduction
The 4-Station Hinge Drilling Machine is an industrial-grade four-station drilling machine for batch processing of cabinet door hinge holes. Through a cyclic multi-station structure, it achieves continuous operation of loading, clamping, drilling, and unloading.
Applications
Cabinet Manufacturing Industry
Used for batch processing of cabinet door hinge holes, ensuring hole consistency and assembly accuracy. Suitable for medium to large-sized cabinet continuous production lines.
Furniture OEM Factories
Suitable for export-oriented OEM orders, achieving standardized drilling processing, reducing human error, and improving delivery stability.
Panel Furniture Processing Plants
Used for mass production of panel furniture, replacing manual drilling processes, improving automation levels, and reducing reliance on manual labor.
Core Advantages
4-Station Continuous System
Four stations operate in parallel, with loading, processing, and unloading occurring simultaneously, reducing waiting time and increasing efficiency by approximately 30%–60%.
High-Precision Positioning System
Mechanical limit and guide structures control the position of the board material, reducing hole deviation and improving batch processing consistency.
Heavy-Duty Machine Frame
Thickened steel frame with stress-reducing design reduces vibration impact and ensures long-term operational stability.
Stable Drive System
Pneumatic/servo control of drilling depth and force ensures consistent processing and stable yield.
How It Works
Loading & Positioning
The sheet metal enters the first station, where positioning and foundation fixing are automatically completed.
01
Automatic Clamping
A pneumatic clamping system secures the sheet metal, preventing processing deviation.
02
Multi-Station Drilling
The second and third stations complete the machining of hinge holes and auxiliary holes, achieving continuous processing.
03
Finishing
The fourth station completes hole finishing, improving edge quality.
04
Unloading
The finished product is automatically output and proceeds to the next process.
05
Technical Specification
|
Item |
Specification |
|
Working Stations |
4 Stations |
|
Max Panel Size |
1200 × 600 mm |
|
Min Panel Size |
150 × 100 mm |
|
Spindle Power |
1.5 kW × 2 (Optional) |
|
Drilling Diameter |
Ø35 mm hinge hole + Ø2 mm screw holes |
|
Air Pressure |
0.6 – 0.8 MPa |
|
Positioning Accuracy |
±0.05 mm (standard condition) |
|
Capacity |
300 – 450 pcs/hour |
|
Machine Weight |
Approx. 1800 kg |
|
Voltage |
380V / 50Hz / 3 Phase (Customizable 220V/415V/440V/60Hz) |
Manufacturing & Quality
In-house Manufacturing
Key structural components are manufactured using CNC machining centers, ensuring machining accuracy and consistency.
CNC Machining
Core components are precision-machined to improve overall machine stability and lifespan.
Inspection
Each machine undergoes operational testing and accuracy checks before leaving the factory.
Export Experience
Adaptable to multiple international voltages and industrial standards, supporting global delivery.
OEM/ODM
Voltage Customization
Supports customization of 220V / 380V / 415V / 440V / 60Hz.
Machine Size
The structure can be adjusted according to production line space and product specifications.
Tooling
Supports rapid customization of fixtures for different sheet metal specifications.
OEM Branding
Supports logo and appearance customization to suit various sales channels.
After-Sales
Installation Support
Provides video and remote guidance for installation and debugging.
Technical Support
Long-term remote technical support to resolve operational issues.
Spare Parts Supply
Long-term supply of standard parts to reduce maintenance costs.
Warranty Service
Standard warranty period, executed according to the contract.
Rapid Response
Rapid feedback and handling mechanism for after-sales issues.
Company Strengths
Extensive Industry Experience
Kanghong Building Materials Technology Co., Ltd. specializes in R&D, manufacturing, and sales of aluminum door, window, and curtain wall equipment. With years of industry focus, the company has built mature production experience and technical know-how.
Strong R&D Capability
Supported by a professional R&D team, the company continuously develops and integrates advanced technologies to improve machining accuracy, production efficiency, and machine stability.
Modern Manufacturing System
Equipped with advanced production facilities and CIMS management systems, we integrate design, manufacturing, and quality control to ensure consistent product quality and efficient delivery.
Strict Quality Control
A full-process quality inspection system is implemented from raw materials to final shipment, ensuring stable performance and reliable machine operation.
Customized Solutions
We provide tailored equipment and production line solutions based on customer profiles, production capacity, and process requirements.
Professional Technical Support
We offer layout design, installation guidance, operator training, and after-sales support, with a 12-month warranty (excluding wear parts) to ensure smooth production startup.
Global Market Experience
With stable quality and professional service, our equipment is exported worldwide and trusted by distributors, manufacturers, and engineering contractors.
FAQ
Q: Is this equipment suitable for high-volume OEM production?
A: Yes. The 4-station circulating structure is designed for continuous batch production, stably supporting medium-to-high-intensity OEM orders, reducing downtime, and suitable for long-term operation in export-oriented furniture factories.
Q: What is the stable production capacity of the equipment in actual production?
A: Under standard board material and conventional hinge hole processing conditions, the capacity is approximately 300–450 pcs/hour, which will vary slightly depending on board size, hole complexity, and operating rhythm.
Q: Will insufficient operator experience affect production quality?
A: The impact is minimal. The equipment adopts an automated positioning and clamping structure, requiring low operator skills. Generally, 1–2 hours of training is sufficient to start operating, making it suitable for general worker environments.
Q: Can the processing accuracy meet export furniture standards?
A: Yes. The equipment uses mechanical limit and guide structures to control hole accuracy, which can be stably controlled within ±0.05mm under standard operating conditions, suitable for export furniture assembly requirements.
Q: Can it operate continuously for extended periods (e.g., 8–12 hours or even longer)?
A: Yes. The equipment features a heavy-duty frame structure and an industrial-grade drive system, suitable for continuous batch production environments in medium to large-sized factories. Under proper maintenance, it can operate stably for extended periods.
Q: Is the equipment easy to maintain, and are spare parts readily available?
A: Maintenance is relatively simple. Key pneumatic and electrical control components use internationally recognized industrial standard models. Wear parts can be sourced locally or supplied by us long-term, reducing downtime risks.
Q: Can it be customized to meet different national voltage standards?
A: Yes. The equipment supports 220V/380V/415V/440V and 50Hz/60Hz customization, adapting to different markets in North America, Europe, Southeast Asia, and the Middle East.
Q: Can the equipment accommodate different sizes of cabinet door panels?
A: Yes. The processing range can be adjusted according to requirements, suitable for different specifications of cabinet doors and panel furniture components. Customized fixture solutions are available to enhance adaptability.
Q: What is the response speed if problems arise during equipment production?
A: We primarily provide remote technical support, typically responding to technical issues within 24 hours. We offer rapid troubleshooting via video or online guidance, and provide spare parts support when necessary.
Q: What is the typical payback period for this equipment?
A: Depending on labor costs and production volume in different countries, the typical payback period is approximately 6–12 months. Return on investment is primarily achieved by reducing labor costs and increasing production capacity.
